AUO
Screen Non-Touch B156HTN03.6 AUO 15.6" LCD Display
Regular price
$150.00 AUD
Regular price
$194.00 AUD
Sale price
$150.00 AUD
Unit price
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
| Manufacturer | AUO | |
| Model Name | B156HTN03.6 (AUO36ED) | |
| Screen Size | 15.6 inch | |
| Screen Type | LCM, a-Si TFT-LCD | |
| Pixel Number | 1920(RGB)×1080 (FHD) 141PPI | |
| Arrangement | RGB Vertical Stripe | |
| Active Area(mm) | 344.16 × 193.59 (H×V) | |
| Outline(mm) | 359.5 × 223.8 × 3.2 (H×V×D) | |
| Bezel Area(mm) | - | |
| Treatment | Antiglare, Hard coating (3H) | |
| Luminance | 220 cd/m² (Typ.) | |
| Contrast Ratio | 400 : 1 (Typ.) (TM) | |
| Viewing Angle | 45/45/15/35 (Typ.)(CR≥10) | |
| Response | 8 (Typ.)(Tr+Td) ms | |
| Good View at | 6 o'clock | |
| Work Mode | TN, Normally White, Transmissive | |
| Color Depth | 262K 45% NTSC | |
| Backlight | 9S5P WLED , 15K hours , With LED Driver | |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) | |
| Refresh Rate | 60Hz | |
| Touchscreen | Without | |
| Signal Type | eDP (2 Lanes) , eDP1.2 , 30 pins Connector | |
| Voltage Supply | 3.3V (Typ.) | |
|
Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
